While there are a number of lathe machines available in the market today, there are some that are specialized and can be used only for specific purposes. These are used for specific purposes and are meant for certain industries.

Industrial Machinery Corporation proudly presents a wide range of Lathe Machines designed to meet the diverse needs of modern machining operations. With our cutting-edge technology, robust construction, and precision engineering, our Lathe Machines empower you to achieve exceptional accuracy, efficiency, and versatility in your machining processes.

VIEW SPECIFICATIONS

Available Options

Maximum Length Required

Min And Max Diameter of the Job

Expected Price

Purchase

Specifications

While there are a number of lathe machines available in the market today, there are some that are specialized and can be used only for specific purposes. These are used for specific purposes and are meant for certain industries.

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear Box
Gear Set

Optional Accessories

Dog Chuck
True Chuck
Electric Motor,
R/F Starte

Lathe Machines

Specifications

Model	BL 4.5'	BL 6'	BL 8'	BL 10'	BL 12'
Length of Bed	4.5	6	8	10	12
Width of Bed	300	350	400	450	500
Height of Center	250	300	350	400	450
Swing Over Bed	500	600	700	800	900
Swing in Gap	700	800	950	1150	1300
Swing Over Saddle	325	375	450	500	550
Admit Between Center	600	900	1300	1800	2250
Spindle Hollow	40	75	90	100	100
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear
Box
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
True Chuck
Electric Motor, Pully

Specialization

Semi Gear Head Model (Belt
Hardened Bed for Long Life (Optional)

Lathe machines

Specifications

Model	L - 4.5'	L - 6.5'	L - 8.5'	L - 10'
Length of Bed	4.5'	6.5'	8.5'	10'
Width of Bed	275	300	325	325
Height of Centre	225	250	300	300
Swing Over Bed	450	500	600	600
Swing in Gap	550	600	725	725
Swing Over Saddle	200	225	250	250
Admit Between Centre	450	1000	1500	1925
Spindle Hollow	40	75	75	75
Power Required	1 H.P.	2 H.P.	3Â H.P.	3 H.P.
Lead Screw Pitch	4	4	4	4
Spindle Speed	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Semi Norton Gear Box
Gear Set

Optional Accessories

Dog Chuck
Motor Pully
Electric Motor,
R/F Starter

Lathe machines

Specifications

Model	LB - 10'	LB - 12'	LB - 14'	LB- 18'	LB - 20'
Length of Bed	10'	12'	14'	18'	20'
Width of Bed	500	500	550	600	650
Height of Centre	450	450	500	550	550
Swing Over Bed	875	875	975	1050	1050
Swing in Gap	1300	1300	1400	1550	1550
Swing Over Saddle	550	550	600	650	650
Admit Between Centre	1800	2250	2700	3600	4050
Spindle Hollow	90	104	104	104	104
Power Required	3Â H.P.	5Â H.P.	7.5 H.P.	10 H.P.	10 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear Box
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
True Chuck
Electric Motor, Pully.

Lathe machines

Specifications

Model	LBL - 4.5'	LBL - 6'
Length of Bed	4'6"	6'
Width of Bed	250	250
Height of Centre	200	200
Swing Over Bed	390	390
Swing Hollow	42	42
Admit Between Centre	500	1000
No. of Spindle Speeds	8	8
Range of Spindle Speeds	50 - 1200	50 - 1200
No. of Feeds	32	32
Range of T.P.I. Thread	4 -- 56	4 -- 56
T.P.I. of Lead Screw	4	4
Power Requirement	2 H.P.	2 H.P.

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
True Chuck
Electric Motor, Pully
Full Norton Gear Box
Extra Feed Shaft

Specialization

Hardened Bed for Long Life (Optional)
More Accurate

Lathe machines

Specifications

Model	LB - 10'	LB - 12'	LB - 14'	LB 18'	LB - 20'
Length of Bed	10'	12'	14'	18'	20'
Width of Bed	500	500	550	600	650
Height of Centre	450	450	500	550	550
Swing Over Bed	875	875	975	1050	1050
Swing in Gap	1300	1300	1400	1550	1550
Swing Over Saddle	550	550	600	650	650
Admit Between Centre	1800	2250	2700	3600	4050
Spindle Hollow	90	104	104	104	104
Power Required	3 H.P.	5 H.P.	7.5 H.P.	10 H.P.	10 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6
