High-Quality IMC Rod Threading Machine | Fast and Accurate Threading for IMC Rods

Rod Threading Machine is use to cut the external threads with the help of Tangential chaser. Chaser is use as a cutter in Machine. Job remain still, Die-head rotates and different type of threads can be cut such as BSPT, BSW, BSP, NPT, UNF, METRIC, UNC, ACME, BSF Threads.

VIEW SPECIFICATIONS

Available Options

Thread Type

Thread Length Require

Diameter of the job

Purchase

Expected Price

Specifications

IMC (Industrial Machinery Corporation) offers rod threading machines that are designed to create threads on rods or bars. These machines are commonly used in industries such as construction, manufacturing, and metalworking, where threaded rods are required for various applications.

Here are some key features and considerations when it comes to IMC's rod threading machines:

Rod Compatibility: IMC's rod threading machines are designed to work with different sizes and types of rods or bars. They can accommodate rods with various diameters, typically ranging from a few millimeters to several inches.

Threading Mechanism: These machines utilize a threading mechanism to create threads on the ends of the rods. The threading process may involve rotating dies or chasers that engage with the rod to cut the threads.

Thread Types: IMC's rod threading machines can create different types of threads, including both internal and external threads. They are capable of producing various thread profiles, such as metric, UNC (Unified National Coarse), UNF (Unified National Fine), ACME, and more.

Power Source: IMC's rod threading machines are typically powered by electric motors. This ensures consistent and efficient operation during the threading process.

Clamping System: These machines feature a clamping system that securely holds the rod in place during the threading operation. The clamping system ensures stability and prevents movement or rotation of the rod, allowing for precise threading.

Durability and Construction: IMC is known for manufacturing sturdy and durable machines. Their rod threading machines are designed to withstand heavy-duty usage and provide reliable performance over time.

Safety Features: IMC's rod threading machines may incorporate safety features such as protective guards and emergency stop buttons. These features help ensure operator safety during the threading process.

It's important to note that specific features and specifications of IMC's rod threading machines may vary based on the model. For detailed information about their specific rod threading machine models, including technical specifications, pricing, and availability, it's recommended to visit the official IMC website or contact their customer support.

When using a rod threading machine, it is essential to follow the manufacturer's instructions and safety guidelines for proper operation and maintenance. Additionally, proper training and protective equipment should be used to ensure safe and efficient threading of rods.

Range of IMC Die Heads.

1/4" to 1" do/-
3/8" to 1.1/2" do/-
1/2" to 2.1/2" do/-

Rod Threading Machine

MODEL	1/4" TO 1" (6MM to 25MM) (BED TYPE)	3/8" TO 1.1/2" (10MM to 40MM) (BED TYPE)	1/2" TO 2.1/2" (12MM to 65MM) (BED TYPE)
Saddle Movement	10"	13"	22"
Spindle Speed Range	75-140	75 -140	45 - 90
Number of Spindle Speed	2	2	2
Threading Capacity	1/4" to 1"	3/8" to 1.1/2"	1/2" to 2.1/2"
Production per Hour	60-80	60-80	70-90
H.P. Required	3 H.P.	3 H.P.	7.5 H.P.
Lead Screw	Optional	Optional	Optional
Weight (KG) Approx.	500	550	990
